- Run Capacitor
- 7.5 UF (MFD – Microfarad)
- 370 V
- Dielectric
- Welded seal
IEC 71533707 7.5 UF MFD ROUND DUAL MOTOR RUN CAPACITOR 370 V
$6.36
Description
IEC run capacitors feature a compact size due to a revolutionary method of winding which allows the highest capability of any film dielectric capacitor on the market. Four blade terminals are provided surrounded by insulators to allow quick installation.
IEC capacitors are made of metalized polypropylene, encapsulated in an oil filled drawn steel seamless can, with double rolled steel cover to provide a leak proof enclosure. The internal current interrupters are designed to disconnect the capacitor element if excessive pressure develops inside casing from misapplication. The IECÂ run capacitors also include welded connections (internal & external) performed with single head electrodes. Each unit has the highest viscosity of any dielectric fluid used in A/C rated capacitors. Individually packaged. GE part # 27L566, Old IEC part # 70005307.
Additional information
| Weight | .03 lbs |
|---|---|
| Dimensions | 3 × 2 × .5 in |
| Brand | IEC |
| Mfd | 1 to 10 |
| Voltage | 370 |
| Material | Metal |
| Description | Parts – Aftermarket |
